Cables

CA-C5-SH-C5 5-Pin Standard Connector / 5-Pin Standard Connector, Shielded Cable

5-pin female standard (friction, not latching) right-angle connectors on both ends of a 5-conductor round shielded 24 AWG cable. This cable is compatible with the E2, E3, H1,...

More CA-C5-SH-C5 Details

CA-C5-SH-FC5 5-Pin Standard Connector / 5-Pin Latching Connector, Shielded Cable

A 5-pin female standard (friction, not latching) connector connected to a 5-pin female polarized latching connector via a 5-conductor round shielded 24 AWG cable. The...

More CA-C5-SH-FC5 Details

CA-C5-SH-NC 5-Pin Standard Connector / Unterminated, Shielded Cable

5-pin female standard (friction, not latching) right-angle connector on one end of a 5-conductor round shielded 24 AWG cable; the other end is unterminated. This cable is...

More CA-C5-SH-NC Details

CA-C5-W4-NC 5-Pin Standard Connector / Unterminated, 4-Wire Discrete Cable

5-pin female standard (friction, not latching) right-angle connector on one end of four individual discrete 22 AWG wires. This cable is compatible with the E2, E3, H1, H3, S1,...

More CA-C5-W4-NC Details

CA-C5-W5-NC 5-Pin Standard Connector / Unterminated, 5-Wire Discrete Cable

A 5-pin female standard (friction, not latching) right-angle connector on one end of five individual discrete 22 AWG wires. This cable is compatible with the E2, E3, H1, H3, S1,...

More CA-C5-W5-NC Details

CA-C10-F-C10 10-Pin IDC Connector / 10-Pin IDC Connector, Flat Cable

10-pin insulation displacement female connectors (IDC) on both ends of a 10-wire flat 28 AWG ribbon cable. This cable is primarily used with Avago/Agilent direct...

More CA-C10-F-C10 Details

CA-C10-SH-C10 10-Pin Standard Connector / 10-Pin Standard Connector, Shielded Cable

10-pin female standard (friction, not latching) connectors on both ends of an 8-conductor round shielded twisted pair 24 AWG cable....

More CA-C10-SH-C10 Details

CA-C10-SH-NC 10-Pin Standard Connector / Unterminated, Shielded Cable

The CA-C10-SH-NC cable has a 10-pin female standard (non-latching) connector on one end of an 8-conductor round shielded twisted pair 24 AWG cable; the other end is...

More CA-C10-SH-NC Details

CA-C10L-SH-NC 10-Pin Standard Connector / Unterminated, Shielded Cable (Avago Pin-Out)

A 10-pin female standard connector on one end of an 8-conductor round shielded twisted pair 24 AWG cable. This cable is primarily used with Avago/Agilent direct replacements...

More CA-C10L-SH-NC Details

CA-CFR-PS-DB9P T7-232 Power and Serial Communication Cable

This cable connects the 5-pin J1 connector of a T7 Networked Absolute Inclinometer (RS232 interface) to a standard PC's DB9 RS-232 serial COM port. The power connector is used...

More CA-CFR-PS-DB9P Details

CA-CFR-PS-NC T7 PUR Shielded Cable with Leads

This PUR (polyurethane) shielded cable has a T7 right angle connector at one end and unterminated wires at the other end. This cable is used with the RS232 or RS485 versions of...

More CA-CFR-PS-NC Details

CA-CFTR-PS-NC T7 PUR Shielded Cable with Leads and Terminating Resistor

This PUR (polyurethane) shielded cable has a T7 right angle connector at one end and unterminated wires at the other end. The cable has a built-in 120-ohm terminating resistor...

More CA-CFTR-PS-NC Details

CA-CM-PS-CFR T7 PUR Shielded Cable

This shielded PUR (polyurethane) cable has a T7 straight connector and a right-angle connector at the other end. You can use this cable with the CON-CAN-MFF splitter to create...

More CA-CM-PS-CFR Details

CA-CM-PS-CFTR T7 PUR Shielded Cable with Terminating Resistor

This shielded PUR (polyurethane) cable has a T7 straight connector at one end and a right-angle connector at the other end. The cable has a built-in 120-ohm terminating resistor...

More CA-CM-PS-CFTR Details

CA-DF5-SH-NC 5-Pin DF52 Connector / Unterminated, Shielded Cable

A 5-pin female polarized straight connector on one end of a 5-conductor round shielded 30 AWG cable. This cable is compatible with the E16 and S16 encoders....

More CA-DF5-SH-NC Details

CA-E15-SH-NC 15-Pin Connector / Unterminated, Shielded Cable

A 15-pin standard cable, 28 AWG.

More CA-E15-SH-NC Details

CA-FC5-SH-FC5 5-Pin Latching Connector / 5-Pin Latching Connector, Shielded Cable

5-pin female polarized latching connector on both ends of a 5-conductor round shielded 24 AWG cable.The high-retention connector is typically used to connect to US Digital's E5,...

More CA-FC5-SH-FC5 Details

CA-FC5-SH-LC5 5-Pin Latching Connector / 5-Pin High-Retention Connector, Shielded Cable

A 5-pin female polarized latching connector connected to a 5-pin female high-retention connector via a 5-conductor round shielded 24 AWG cable. The high-retention connector is...

More CA-FC5-SH-LC5 Details

CA-FC5-SH-MIC3 5-Pin Latching Connector / 3-Pin Micro Connector, Shielded Cable

This cable consists of a 5-pin latching connector on one end of a shielded cable and a 3-pin micro connector on the other end. This cable is used to connect the PWM output...

More CA-FC5-SH-MIC3 Details

CA-FC5-SH-MIC4 5-Pin Latching Connector / 4-Pin Micro Connector, Shielded Cable

This cable consists of a 5-pin latching connector on one end of a shielded cable and a 4-pin micro-connector on the other end. This cable is used with several different products...

More CA-FC5-SH-MIC4 Details

CA-FC5-SH-NC 5-Pin Latching Connector / Unterminated, Shielded Cable

A 5-pin female polarized latching connector on one end of a 5-conductor round shielded 24 AWG cable. This cable is compatible with the E5, E6, HB5M, HB6M, H5, H6, S5, and S6...

More CA-FC5-SH-NC Details

CA-FC5-SH-RC7 5-Pin Latching Connector / 7-Pin MIL-C-5015 Connector, Shielded Cable

This shielded cable connects to US Digital's HD25 Industrial Rugged Metal Optical Encoder via a circular 7-pin screw-on connector, and it has a 5-pin latching connector on the...

More CA-FC5-SH-RC7 Details

CA-FC5-W4-NC 5-Pin Latching Connector / Unterminated, 4-Wire Discrete Cable

The CA-FC5-W4-NC discrete wire encoder cable has a 5-pin female polarized latching connector on one end of four individual discrete 22 AWG wires; the other end is unterminated....

More CA-FC5-W4-NC Details

CA-FC5-W5-NC 5-Pin Latching Connector / Unterminated, 5-Wire Discrete Cable

A 5-pin female polarized latching connector on one end of five individual discrete 22 AWG wires. This cable is compatible with the E5, E6, HB5M, HB6M, H5, H6, S5, and S6...

More CA-FC5-W5-NC Details

US Digital CA-FC10-SH-FC10 Product Photo

CA-FC10-SH-FC10 10-Pin Latching Connector / 10-Pin Latching Connector, Shielded Cable

10-pin female latching connectors on both ends of an 8-conductor round shielded twisted pair 24 AWG cable....

More CA-FC10-SH-FC10 Details

CA-FC10-SH-NC 10-Pin Latching Connector / Unterminated, Shielded Cable

A 10-pin female latching connector on one end of an 8-conductor round shielded twisted pair 24 AWG cable....

More CA-FC10-SH-NC Details

CA-FC10-W8-NC 10-Pin Latching Connector / Unterminated, 8-Wire Discrete Cable

A 10-pin female polarized latching connector on one end of eight individual discrete 22 AWG wires....

More CA-FC10-W8-NC Details

US Digital CA-FC10L-SH-FC10L Product Photo

CA-FC10L-SH-FC10L 10-Pin Latching Connector / 10-Pin Latching Connector, Shielded Cable (Avago Pin-Out)

10-pin female polarized latching connectors on both ends with an 8-conductor round shielded twisted pair 24 AWG cable. This cable is primarily used with Avago/Agilent direct...

More CA-FC10L-SH-FC10L Details

CA-FC10L-SH-NC 10-Pin Latching Connector / Unterminated, Shielded Cable (Avago Pin-Out)

A 10-pin female polarized latching connector on one end of an 8-conductor round shielded twisted pair 24 AWG cable. This cable is primarily used with Avago/Agilent direct...

More CA-FC10L-SH-NC Details

CA-FC10P-SH-NC 10-Pin Latching Connector / Unterminated, Shielded Cable (QSB-D QSB-M Pin-Out)

A 10-pin female polarized latching connector on one end of a 10-conductor round shielded twisted pair 24 AWG cable. Please note: This cable is intended for use with the digital...

More CA-FC10P-SH-NC Details

CA-LC5-SH-LC5 5-Pin High-Retention Connector / 5-Pin High-Retention Connector, Shielded Cable

5-pin female high-retention connectors on both ends of a 5-conductor round shielded 24 AWG cable. This cable is compatible with the E2, E3, H1, H3, S1, and S2 encoders and with...

More CA-LC5-SH-LC5 Details

CA-LC5-SH-NC 5-Pin High-Retention Connector / Unterminated, Shielded Cable

A 5-pin female high-retention connector on one end of a 5-conductor round shielded 24 AWG cable. This cable is compatible with the E2, E3, H1, H3, S1, and S2 encoders and with...

More CA-LC5-SH-NC Details

CA-LC5-W4-NC 5-Pin High-Retention Connector / Unterminated, 4-Wire Discrete Cable

A 5-pin female high-retention connector on one end of four individual discrete 22 AWG wires. This US Digital cable is compatible with non-index versions of the E2, E3, H1, H3,...

More CA-LC5-W4-NC Details

CA-LC5-W5-NC 5-Pin High-Retention Connector / Unterminated, 5-Wire Discrete Cable

A 5-pin high-retention connector on one end of five individual discrete 22 AWG wires. This cable is compatible with the E2, E3, H1, H3, S1, S2 encoders and with the EM1 and EM2...

More CA-LC5-W5-NC Details

CA-MCL3-SH-NC 3-Pin Micro-Lock Plus Connector / Unterminated, Shielded Cable

A shielded 26 AWG round cable with a 3-pin Molex Micro-Lock Plus connector on one end. Connector housing: Molex# 5055650301 Connector individual crimp-on pins: Molex#...

More CA-MCL3-SH-NC Details

CA-MD3 USB to RS485 Adapter Cable for MD3

The CA-MD3 is an interface cable that connects a PC's USB port to an RS485 interface. The RS485 connector is a 6-pin RJ25 modular connector, and designed for US Digital's MD3...

More CA-MD3 Details

CA-MD6-SH-MD6 6-Pin Modular Connector / 6-Pin Modular Connector, Shielded Cable

6-pin modular connectors on both ends of an 8-conductor shielded round twisted pair 26 AWG cable....

More CA-MD6-SH-MD6 Details

CA-MD6-SH-RC10 6-Pin Modular Connector / 10-Pin MIL-C-5015 Connector, Shielded Cable

A 10-pin MIL-C-5015 female connector connected to a 6-pin modular connector via an 8 conductor shielded round twisted pair 26 AWG cable....

More CA-MD6-SH-RC10 Details

CA-MD6-SS-MD6 6-Pin Modular Connector / 6-Pin Modular Connector, Unshielded Cable

A 6-pin modular connector on both ends of an unshielded silver satin 28 AWG cable....

More CA-MD6-SS-MD6 Details

CA-MD6A-SS-MD6 6-Pin Modular Connector / 6-Pin Modular Connector, Unshielded Cable (A2 Analog)

6-pin modular connectors on both ends of an unshielded silver satin 28 AWG cable. This cable is intended for connecting a single analog output A2 version of US Digital's A2...

More CA-MD6A-SS-MD6 Details

CA-MIC3-SH-NC 3-Pin Micro Connector / Unterminated, Shielded Cable

A 3-pin micro mating connector on one end of a 4-conductor shielded round 26 AWG cable....

More CA-MIC3-SH-NC Details

CA-MIC3-W3-NC 3-Pin Micro Connector / Unterminated, 3-Wire Discrete Cable

A 3-pin micro mating connector on one end of three individual discrete 26 AWG wires....

More CA-MIC3-W3-NC Details

CA-MIC4-SH-NC 4-Pin Micro Connector / Unterminated, Shielded Cable

A 4-pin micro mating connector on one end of a four-conductor round twisted pair 26 AWG cable....

More CA-MIC4-SH-NC Details

CA-MIC4-W4-NC 4-Pin Micro Connector / Unterminated, 4-Wire Discrete Cable

A 4-pin micro mating connector on one end of four individual discrete 26 AWG wires....

More CA-MIC4-W4-NC Details

CA-MIC6-SH-NC 6-Pin Micro Connector / Unterminated, Shielded Cable

A 6-pin micro connector on one end of a 6-conductor round twisted pair 26 AWG cable....

More CA-MIC6-SH-NC Details

CA-MIC6-W6-NC 6-Pin Micro Connector / Unterminated, 6-Wire Discrete Cable

A 6-pin micro connector on one end of six individual discrete 26 AWG wires....

More CA-MIC6-W6-NC Details

CA-PCL6-SH-NC 6-Pin Pico-Clasp Connector / Unterminated, Shielded

A 6-pin Molex Pico-Clasp (# 5013300600) series, 1.0mm pitch plug connector on one end of a 6-conductor round shielded 28 AWG cable. This cable has a temperature range of -40C to...

More CA-PCL6-SH-NC Details

CA-RC7-SH-NC 7-Pin MIL-C-5015 Connector / Unterminated, Shielded Cable

A 7-pin MIL-C-5015 female connector on one end of a 7-conductor shielded round 24 AWG cable. This low-temperature cable (-20C to +80C) is used with US Digital's HD25 Industrial...

More CA-RC7-SH-NC Details

CA-RC10-SH-NC 10-Pin MIL-C-5015 Connector / Unterminated, Shielded Cable

A 10-pin MIL-C-5015 female connector on one end of a 12-conductor shielded round 24 AWG cable. This low-temperature version has a range of -20C to +80C....

More CA-RC10-SH-NC Details
